油煙凈化器是對餐飲油煙和惡臭污染物進行收集及凈化處理的設備，幾乎不管是在自己家里還是在飯店餐館都能見到，那么您知道它的具體安裝規范步驟嗎？下面濟南油煙凈化器廠家為您解答。

The lampblack purifier is a device for collecting and purifying cooking fume and malodorous pollutants. It can be seen almost at home or in restaurants. Do you know the specific installation procedures? Now Jinan lampblack purifier manufacturer will answer for you.

安裝順序：灶頭→集煙罩→通風管道→油煙凈化器→通風管道→風機，油煙凈化器應安裝在排風機之前，并且盡可能靠近集氣罩，油煙凈化器和管道應密封完好，無破損、無泄漏；

Installation sequence: stove → smoke collecting hood → ventilation duct → lampblack purifier → ventilation duct → fan. The lampblack purifier should be installed in front of the exhaust fan and as close to the gas collecting hood as possible. The lampblack purifier and pipe should be sealed well without damage or leakage;

飲食單位宜采取高空排放的，排風口應高于地面15米或所附屬建筑物屋頂1.5米；不宜采取高空排放的，按標準采取室內凈化或低空排放；不得將油煙排入下水管道；

If the dining unit should discharge at high altitude, the air outlet should be 15 meters above the ground or 1.5 meters above the roof of the attached building; If high altitude discharge is not suitable, indoor purification or low altitude discharge shall be adopted according to the standard; The lampblack shall not be discharged into the sewer pipe;

含有室內燒烤的飲食單位應安裝一體化燒烤機，并對排出的油煙進行二次凈化。

The catering unit with indoor barbecue shall install an integrated barbecue machine and conduct secondary purification for the lampblack discharged.

凈化設備應與排風機聯動，油煙凈化器的風量應與排風機的風量一致，每個基準灶頭少2千風量；

The purification equipment shall be linked with the exhaust fan, and the air volume of the lampblack purifier shall be consistent with that of the exhaust fan, with at least 2000 air volumes for each benchmark stove;

爐灶、蒸箱、烤爐（箱）等產生煙氣的加工設施上方應設置集氣罩，油煙集氣罩罩口投影面積應大于灶臺面，罩口下沿離地面適宜高度在1.8米左右；

A gas collecting hood shall be set above the processing facilities that produce smoke, such as stoves, steam ovens, ovens (ovens), etc. The projected area of the hood opening of the lampblack gas collecting hood shall be larger than the kitchen top, and the appropriate height from the lower edge of the hood opening to the ground shall be about 1.8 meters;

油煙氣排風水平管道應設置坡度，坡面滑向集油、放油或排凝結水處，設置排油管口，管道應密封無滲漏；

The oil smoke and gas exhaust horizontal pipe shall be set with gradient, and the slope shall slide to the place where oil is collected, drained or condensed water is drained. The oil drain pipe orifice shall be set, and the pipe shall be sealed without leakage;

監測采樣孔應設置內徑不小于8厘米的圓形或方形監測口，檢測口應采用活動擋板，檢測時打開，監測完成后密閉；

The monitoring sampling hole shall be equipped with a circular or square monitoring port with an inner diameter of no less than 8 cm. The testing port shall be equipped with a movable baffle, which shall be opened during testing and closed after monitoring;

餐飲服務企業應建立環境保護管理制度，專人或委托第三方運營管理、維護保養油煙凈化器，定期清理并按規定及時登記，由轄區執法中隊定期驗收簽字，油煙凈化器清洗包含但不于（集氣罩、油煙凈化器、除異味裝置、風機、排放通道）等，集煙罩清潔無油污，凈化器和排氣筒周圍無油污污染地面或油煙熏黑墻壁。

Catering service enterprises shall establish an environmental protection management system, assign special personnel or entrust a third party to operate, manage, maintain and maintain the lampblack purifier, clean it regularly and register it in a timely manner as required. The law enforcement squadron in the jurisdiction shall regularly accept and sign. The lampblack purifier cleaning includes but is not limited to (gas collecting hood, lampblack purifier, odor removal device, fan, emission channel), etc. The lampblack purifier shall be clean and free of oil contamination, There is no oil stain around the purifier and exhaust funnel to pollute the ground or smoke the walls.

油煙凈化設備的外觀完好、整潔、標識齊全，應當在顯著位置設置標牌，標明產地、規格型號、處理風量、凈化效率、高進口油煙濃度、設備阻力、產地、廠名、廠家地址及聯系方式、出廠日期、使用年限及生產編號等。關注我們http://www.tianhaichuan.com，了解更多相關事項！

The appearance of lampblack purification equipment shall be intact, neat and complete, and the identification shall be complete. A sign shall be set at a prominent position, indicating the origin, specification and model, treatment air volume, purification efficiency, high imported lampblack concentration, equipment resistance, origin, factory name, manufacturer address and contact information, date of manufacture, service life, production number, etc. Follow us http://www.tianhaichuan.com , learn more about it!
